Semi-Auto Chemistry Analyzer

Semi-Auto Chemistry Analyzer MIT520-9 Features: Easy Windows operation system with large touch-screen Displays the reaction curve in real-time Continuously adjustable grating, enhances the stability and reliability of result Reagent-open system supports flow cell and cuvette mode, close system on request Analytical modes include kinetic, fixed time, bichromatic end point with or without reagent blank or sample blank, linear or non-linear calibration Large memory, up to 200 test protocols and 10000 results can be stored, compatible with SD card Powerful QC program: Westguard multi-rule, Levey-Jennings plots,2 controls per test Multiform result output including patient comprehensive report Multi-interface support RS-232,VGA,USB,SD and Ethernet Easy communication with PC Powerful internet connection enables remote data sharing and OS update Compact design enables USER-DIY maintenance Multi-language software available on request Technical Specifications: General Descriptions Absorbance Range -0.500 - 3.500Abs Resolution 0.001 Abs (displayed), 0.0001Abs (calculated) Light Source Halogen lamp, 12V/20W Wavelengths Continuously adjusted grating, wavelength range is 330 - 800nm, 1nm by step adjustment Wavelength Accuracy ± 1nm Band Width < 6nm Flow Cell Metal - quartz flow cell Temperature Control 25,30,37,±0.1 and ambient temperature Carryover < 1% Memory 200 test protocols, up to 10000 test results, support SD to expand memory Display 6.4" color/mono LCD Output Built-in printer or external printer Input Touch screen, mouse and keyboard optional Interface RS-232,support VGA,2 USB, SD, Ethernet Language English or any language on request Power Supply AC 100V - 240V ± 10%,50-60Hz Net Weight 11KG Dimensions L × W × H (mm) 370 x 284 x 318
